Machine List

At Demtool Inc., we have invested in the latest equipment and technology to provide our customers with the highest quality components, parts, and services. Listed below are just some of the state-of-the-art equipment we use to meet the needs of customers.

Fabrication Equipment

Laser Cutting



Key Features and Capabilities:

  • Sheet metal up to 5' x 10'
  • 10000 watt fiber
  • Beam shaping
  • Automatic nozzle changer
  • Bystronic Bysoft & Plant Manager's advanced 2D nesting and production software maximize material utilization and production

Stock Material Thicknesses:


  • Mild Steel ¾″

  • Stainless Steel ½″

  • Aluminum ½″

  • Copper ¼″

  • Brass ¼″

In certain circumstances we can acquire other materials and thicknesses, or use customer supplied materials.

Forming


Key Features and Capabilities:

  • Up to 250 tons
  • Parts up to 13' long (4000mm)
  • Dynamic crowning
  • Laser angle measurement system
  • 6 axis backgauge
  • 18" stroke, 29" daylight
  • Offline 3D programming

Our Brake Press Equipment:

  • Bystronic Xpert 250
  • Bystronic Xpert Pro 150
  • Bystronic Xpert 80
  • Bystronic Xcite 80

Welding

MIG / TIG

  • Miller Dynasty 400 (4)
    • advanced weld parameter controls
    • hydro efficient
  • Lincoln 350 MP (4)
    • Python aluminum push pull
  • Miller 252, 220, and 211 series welders
  • Rotary weld positioners

Stud Welding

Grizzly Pro

  • Up to 5/16" Stainless Steel, Mild Steel, and Aluminum studs
  • Enhanced duty cycle
  • Digital voltage controls

Spot Welding

Alpha Control AF-2A

  • 75kva
  • Controller with weld profile parameters
  • Long arms allow for welding in tricky to reach positions

Other Fabrication

Rolling

  • Akyapak ASK 130
  • Parts up to 60" wide at 3/16" thick
  • Tapers achievable
  • NC control for repeatability
  • Hand rolls for smaller diameters

Deburring

Fladder AUT-100

  • Edge rounding all profiles without affecting surface finish
  • Rotating and oscillating sanding brushes
  • 40" wide part capacity

Vibra PT-5

  • Tumble deburring of parts made from any material
  • Deburrs, descales, cleans and coats with corrosion protection

PEM insertion

PennEngineering PS4

Haeger HP6-B

  • 6 Ton insertion force
  • 18" throat depth
  • Wide variety of tooling and insertion hardware

Machining Equipment

CNC Milling


Key Features and Capabilities:

  • Spindle speeds up to 15000 rpm
  • Max table size Y - 45" X - 81"
  • High speed 2D & 3D dynamic toolpaths
  • Latest Mastercam multi axis software

Equipment:

  • Matsuura VX-1000
  • First MCV-1100
  • First V2000
  • First V700 (2)
  • First V43
  • Tree VMC 1060 (3)

CNC Turning


Key Features and Capabilities:

  • Spindle speeds up to 6000 rpm
  • Live tooling
  • Max diameter - 13.75"
  • Max length - 23.625"
  • 2.5" diameter bar feed capacity up to 12' long
  • Latest Mastercam multi axis software

Equipment:

  • Nakamura AS200MY with bar feeder
  • Nakamura Tome SC-300
  • Hyundai HIT160 with bar feeder

Manual Machining

Saw Cutting

  • Bomar Ergonomic 320 (2)
    • 10" diameter bar capacity
    • 12" plate width
  • Cold cut saw

Milling

  • Maximart 3VS knee mill (5)
    • 10" x 54" Table
  • Bowes 4' radial arm drill
  • TOS  FGV 32 roughing mill with 50 taper
    • 12" x 40" table

Turning

  • Ecoca SJ660
    • 26" swing
    • 80" between centers
    • 4" spindle bore
  • Microweily TY 2000
    • 18" swing
    • 63" between centers
    • 2.3" spindle bore


Powder Coating

Powder System

Overhead Conveyor System

  • 50 lbs per hanger
  • Hanger area: 25"x60"x12"
  • Parts can span multiple hangers (up to 100 lbs and 96" long)

Wash and Dry

  • Automated 5 stage wash wash using organic solution
  • Air knife blower and infra-red dryer

Powder Application

  • Filtered spray booth
  • Eurotec GCU400 paint gun

*NEW* - Batch oven

  • Infra-red heaters
  • Gas convection oven
  • Maximum product size 96" High 96" wide 348" long in Batch Oven**

** Depending on product geometry and weight the maximum size might be less. Drawings should be provided to verify.
